Cylinder PMMA Lucite Clear Transparent Acrylic Sheet For Acrylic Pool

Large Image : Cylinder PMMA Lucite Clear Transparent Acrylic Sheet For Acrylic Pool

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	AUPOOL
Model Number:	AP-PMMA acrylic panel

Payment & Shipping Terms:

Minimum Order Quantity:	1pc
Price:	$273.00/square meters
Packaging Details:	1.pp bags <br>2.with wooden case
Supply Ability:	20000 Kilogram/Kilograms per Month

Contact Now

Cylinder PMMA Lucite Clear Transparent Acrylic Sheet For Acrylic Pool

Description

Type:	Pool	Product Name:	AUPOOL Cast Acrylic Sheets For Swimming Pool
Material:	PMMA, Lucite, Acrylic	Color:	Clear, Transparent
Application:	Undersea World, Oceanarium, Zoo, Luxurious Hotels, Swimming Pools	Density:	1.2g/cm3
Thickness:	According Water Depth	Advantage:	Seamless Splicing
Feature:	Easy Install+30 Years Outdoor Use Non-yellowing	Shape:	L/U/flat/tunnel/cylinder
Technology:	Cast	Port:	Shenzhen

Product Description

Cast Acrylic Panel

Acrylic Panel Shape: Flat / Tunnel/ Cylinder or Custom

Acrylic Panel Turnkey Projects

1	Transparent swimming pool scheme design
2	3D rendering design
3	Acrylic installation node sample design
4	Design and safety verification
5	Use new high-quality Lucite (Lucite) PMMA raw materials
6	Dry constant temperature polymerization
7	Finished grinding
8	CNC Machining
9	Thermoforming
10	seamless splicing
11	polishing
12	Quality Control
13	Acrylic packaging
14	Acrylic Transport
15	Lifting experience
16	Installation and construction

Specification

Below molding sizes are for your reference. Please note that: below size (molding size) ≠ panel net size
Size	Thickness	Size	Thickness
1300x2500mm	30-70mm	1350x2650mm	30-100mm
1450x2700mm	30-100mm	1600x2600mm	30-100mm
1650x3150mm	30-100mm	2200x3200mm	30-110mm
1650x3500mm	30-100mm	2750x4250mm	30-130mm
1800x5000mm	30-150mm	2100x5500mm	30-150mm
3000x6200mm	50-250mm	3000x6700mm	50-250mm
3000x8200mm	80-250mm	3000*8700mm	80-250mm
3000x11500mm	100-250mm	3700x8100mm	120-300mm

NO.	Physical Property	ISO	Unit	Result
1.	Specific gravity / density	D792	Kg/m	1175
Optical
2.	Luminous Transmittance	GB/T2410-2008	%	92.6
3.	Haze	GB/T2410-2008	%	1.8
Mechanical
4.	Tensile Strength	527-2:2012
	a) Maximum tensile strength		MPa	80.7
	b) Elongation at break		%	4
	c)Tensile modulus		MPa	3010
5.	Flexural Strength	178:2010
	a) Maximum flexural strength		MPa	87.7
	b) Maximum flexural strength		MPa	2900
6.	Comintsane Yield Stress	604:2002	MPa	No Yield Point
7.	Izod Notched Immpact Stress	D256-10 (Method c)	J/m	8
8.	Shear Strength	D732-10	MPa	62.5
9.	Rockwell Hardness	2039-2:1987	HRL	105
Thermal
10.	Flammability	UL94-2013 (7)	mm/min	24.1
11.	Heat Deflection Temperature	75-2:2013(Method B)	°C	106.2
12.	Glass Transition Temperature	11357-2:1999
	a)Teig		°C	105.6
	b)Tmg		°C	114.0
	c)Tefg		°C	122.3
13.	Coefficient of Linear Thermal Expansion	11359-2:1999	°C	-40 to 110
	a)Parallel to flow		um/m-°C	78.60
	b)Perpendicular to flow		um/m-°C	80.56
Others
14.	Water Absorption	62:2008	%	0.12
15.	Odor			None
16.	Taste			None

Product Name	Acrylic pool	Shape	Customer's Demand
Brand	AUPOOL	Color	Clear/transparent
Material	PMMA Lucite Acrylic	Place of Product	Guangdong Province,China
Surface	High Surface Hardness	Modes of packing	PE film masking on both sides,KT board and angle iron.
Thickness	30-950 mm customized	Light transmission	High light transmission(93%)

Detailed Images

AUPOOL acrylic thick plate adopts dry constant temperature polymerization method production process, acrylic plate reaches the best polymerization temperature, and its performance is obviously superior to the traditional pool bath method of other manufacturers. The structure of AUPOOL acrylic sheet is stable, and it will not yellow for 30 years outdoors. The safety accident rate has been zero in the past 30 years since the establishment of the factory, escorting your personal safety.

AUPOOL is currently the technology brand with the most R&D strength and market potential in the acrylic transparent swimming pool industry. Since its establishment, it has completed more than 1,000 acrylic transparent swimming pool projects in 83 countries and regions around the world; it has formed strategic cooperation with 180+ design institutes, 50+ real estate companies, and 70+ large hotel chains; it has good brand awareness and Influence.

Our annual production reaches 5000 tons of thick plates. We have the most advanced dry-type constant temperature polymerization process production line and equipment; we have the most mature acrylic ultra-thick plate production capacity and equipment, and the thickest plate actually put into use reaches 950mm; we have first-class seamless splicing technology, splicing seams Concealed, the strength and transparency of the stitching seams are almost the same as the whole board.

Our company is equipped with a professional structural team for each project, as well as assistance and technical support from the Institute of High Energy Physics, Chinese Academy of Sciences. Our company will conduct finite element analysis of acrylic strength for each project, and comprehensively evaluate the stress of acrylic sheets from the aspects of material mechanical properties, physical properties, on-site environmental constraints, service conditions and working conditions, and the water pressure and waves caused by the proposed project. The influence of dynamic pressure and wind pressure,analyze the stress effect and tensile strength of the acrylic plate, analyze the risk of fracture and plastic deformation, and ensure that scheme design, physical properties and safety factor of each acrylic plate are fully up to standard, and the completion can meet the needs of use and ensure the safety of the project

Project Cases

Company Introduction

Certificate

Packing&Shipping

1.pp bags 2.with wooden case

FAQ

Q1. What are the main challenges in implementing large transparent window projects? The main challenges in implementing large transparent window projects include ensuring safety, understanding the performance of acrylic sheet materials, designing the application of transparent windows, and having experience in the installation process. Q2. Why is it important to work with a professional acrylic sheet manufacturer for these projects? It is important to work with a professional acrylic sheet manufacturer for large transparent window projects because they have expertise in understanding the performance of acrylic sheet materials and have experience in designing and installing transparent windows. Q3. What kind of expertise is required for designing and installing transparent windows? Designing and installing transparent windows requires expertise in understanding the performance of acrylic sheet materials, designing the application of transparent windows, and having experience in the installation process. Q4. How does your company ensure the safety and quality of its transparent window projects? Our company ensures the safety and quality of its transparent window projects by using the most advanced project management methods, organizing a team of experts, and calculating, verifying, and planning each step of the design, installation, and use process. Q5. What are some risks of choosing unscrupulous suppliers for transparent window projects? The risks of choosing unscrupulous suppliers for transparent window projects include the use of low-quality materials, such as water-bath polymerization sheets, which can lead to problems such as discoloration, cracking, and decreased transparency. This can ultimately harm the reputation of the entire industry and cause inconvenience to customers. Q6. How long have your technical and management staff been working in the acrylic sheet industry? Our technical and management staff have been working in the acrylic sheet industry for more than 10 years, gaining extensive experience in solution design, deepening solutions, validating solutions, engineering construction, and post-sales support. Q7. Does your company provide after-sales support for transparent window projects? Yes, our company provides after-sales support for transparent window projects through our comprehensive after-sales support team.
